CLAAS V-belt part no. 00 0628 785 0 Agrosikora

V-belt in the combine harvester drive system

Catalogue number00 0628 785 0refers tothe V-belt for a CLAAS combine harvester, which plays a vital role in the drive transmission system. Thanks to theV-shaped cross-section of the belt, it can effectively wedge into the pulley grooves, ensuringefficient torque transmissionand power with minimal slip. As a flexible component, the belt is not only functional but also protects other system elements from overload.

Where is the V-belt located in the combine harvester?

V-belts are present in many combine components because they enablepower transmission from the engine to the working components. The belt with number00 0628 785 0may be found in locations such as:

• Threshing drum and cleaning system drive – includingthe fan and straw walkers.
• Drive for the fan, alternator, and hydraulic pump – as part of auxiliary systems.
• Drive variator – if the belt functions in a variable ratio.

Exact placement depends on the configuration of the specific machine model, as CLAAS uses many drive system variants.

Most important functions of the V-belt

CLAAS V-beltis not just a drive carrier – its design also provides additional benefits for the machine's service life. Main functions include:

• Effective drive transmission between components.
• Reduction of oscillations and vibrations, which could negatively affect other drive parts.
• Quiet machine operation – compared to chains or gears.
• System safety – the belt can slip in case of a blockage, preventing damage.
• Maintaining synchronization of unit operation, which is crucial for uniform material flow in the machine.

Application in CLAAS combine models

The V-belt with designation00 0628 785 0is used in many CLAAS machines. Typical series in which it may occur include:

• CLAAS LEXION – models from the 400, 500, 600, and 700 series.
• CLAAS TUCANO – models from the 300, 400, and 500 series.
• CLAAS MEGA / MEDION / DOMINATOR – depending on the version and drive configuration.

Due to the diverse range of applications, we recommend contacting us.
