Switch for CLAAS combine harvester cat. no. 00 0011 815 3 Agrosikora

Electrical switch for CLAAS control systems

CLAAS electrical switch(cat. no.00 0011 815 3) is anessential electrical system component, which enables manualswitching of circuits on and off. It can operate as a simple ON/OFF switch or feature mode-switching functions, depending on its design and purpose. It is used in many combine harvester systems, from lighting to working system controls.

Where the switch is located in the harvester

CLAAS switchesare placed in locations that ensure quick and convenient access for the operator. Common locations include:

• In-cab control panel– for operating lights, air conditioning, radio, or wipers.
• Side console– for activating working functions, e.g., grain tank unloading, header lifting.
• Control levers– integrated function switches.
• Service panels– for activating test or diagnostic modes.

The locationof the CLAAS electrical switchdepends on its function and the type of machine.

Application and key functions

The CLAAS switchplays an important role inthe operation and control of harvester functions. Thanks to it, the operator can activate selected systems or switch device operating modes from the cab.

Key functions:

• Switching functions on/off– control of basic circuits such as lights or ventilation.
• Changing operating modes– multi-position switches can handle various settings.
• Safety– it can serve asan emergency switchor a lockout system.
• Simple operation– intuitive form of control, resistant to field working conditions.

Application in CLAAS combine harvesters

Switch 00 0011 815 3is used in many CLAAS machine models as an element ofthe operator panelor auxiliary systems. Most commonly found in:

• CLAAS LEXION– 400–700 series models, for cab operation, lighting, and working systems.
• CLAAS TUCANO– 300–500 versions, in control panels and auxiliary modules.
• CLAAS MEGA, MEDION, DOMINATOR– also in older models, depending on the equipment version.

If you want to ensure that theCLAAS switchwill fit your machine, please contact us.
